All American Model #75X - 41 Qt. Electric Sterilizer

Wisconsin Aluminum Foundry was first in the field to develop an immersion-type pressure sterilizer for physicians’ offices, hospitals and laboratories. The electric ALL-AMERICAN® Sterilizer is a complete, self-contained unit with an immersion heating element, automatic thermostatic control, automatic release valve, and pilot light. It connects to any outlet, is ready for use instantly, and ensures complete, efficient sterilization.

Model 75X-120: 120 Volt, 50/60 Hz 1650 watts/13.75 amps
Model 75X-240: 240 Volt, 50/60 Hz 1650 watts/6.88 amps
Gross Capacity	41 qt / 39 liter
Overall Height	19" / 48.3cm
Bottom Height	14 1⁄4" / 36.2cm
Inside Diameter	15 1⁄4" / 38.7cm
Unit Weight	45 lbs. / 20.4kg.
Inner Container No. 4156
Height	45 lbs. / 20.4kg.
Diameter	14" / 35.6cm
Circumference	14" / 35.6cm
Capacity	27.3 qt / 25.8 liter
Volume	1578in³ / 25,856cm³
Carton Dimensions	24" x 24" x 21" 61cm x 61cm x 53.3cm
Shipping Weight	51 lb. / 23.1kg.
Unit Pack: 1	Cube: 7
Optional No. 4180 Support Base	3" / 7.6cm high
Outside Diameter	16 1⁄4" / 41.3cm
Inside Diameter	15" / 38.1cm
Elevates Sterilizer Above Surface	2 1⁄4" / 5.7cm

• 64% greater capacity compared to 25X
• 120 or 240 volt operation
• 1650 watt heating element for faster operation
• More accurate TPI thermocouple, snapswitch and pilot light
• 60 minute mechanical bell timer
• Extra large 41 qt/39 liter capacity
• Operational on 50Hz or 60Hz
• Calrod immersion heating element
• 3-wire grounded cord and plug for safety
• Optional support bases elevate electric sterilizers above table or counter surface to prevent heat damage
• UL approved
• One year warranty
• Units include aluminum inner container with rack
• Interior stainless steel support stand
• Made in U.S.A.
• Optional support base elevates electric sterilizers to prevent intense heat from damaging counter top or work surface.

Shipping Disclaimer: We only ship this product to the 48 contiguous states. We do not ship this item to Alaska, Hawaii, or any U.S. territories.
